Nux MG300 Guitar Modelling Processor Multi Effects Pedal

Pre Effects Empowered by NUX TSAC-HD Technology

We've all experienced digital pre effects pedals that belong on the Wall of Shame -, especially Overdrive. Modellers of this kind used the linear algorithm which doesn't provide negative-feedback for dynamic playability. Enter the NUX MG-300, the modeller that will totally blow your mind! The pre-effect block beautifully recreates the awesome signature sound of real analog overdrive/distortion pedals

In 2010 NUX introduced TSAC (True Simulation of Analog Circuit) with the sole intention of bringing Amp Modeling to a whole new level. The DSP industry has been evolving at breakneck speed, and keeping up can be a challenge. Nux was impressed that a product like the Fractal® AX-FX had the foresight to use a high-definition TSAC (white-box) algorithm to do its Amp Modeling. So we took note and started development on an affordable modeller with TSAC-HD.

When you tweak the knob, it affects itself as well as other parameters. For a linear digital system, the parameter is independent. The white-box algorithm offers real negative-feedback, increment-by-increment. NUX TSAC-HD replicates the same playability most guitarists prefer in a real tube amplifier.

Building a sky-high priced product is easy. The art of building an affordable product is a real challenge.

Impulse Response for Cabinet Simulation

NUX is well-known for Impulse Response technology. Using IR is the most popular way to do cab simulation today. Why? Because the sound is noticeably more realistic compared to traditional cab simulation.

 MG-300 offers a 512 sample resolution of an impulse response. You can load 3rd party IR files using NUX QuickTone edit software. ( MG-300 supports 48kHz Wav format. ) The built-in 25 cabinets IRs combine 4 classic microphones with 3 positions to allow beginners a quick and easy way to jump into the multi-effects experience.

Jam with the Drum Machine and Looper

MG-300 supports NUX Phrase Loop Synchronization with Rhythm - a breakthrough technology derived from the popular NUX Loop Core Stompbox and later the JTC Pro Drum & Loop. Every guitarist has his/her own funky way so a truly versatile drum & looper is indispensable. MG-300 has 8 rhythm styles, each style has 7 different beats. You can play the rhythm then record your phrase loop. MG-300 will automatically amend the phrase to fit the current rhythm BPM.

MG-300 offers 60s phrase loop recording time

Connect to NUX Quick Tone™, and you can easily tweak parameters, download patches, load 3rd party IRs, and even set up USB audio-stream routing. Quick Tone is an interactive edit software - when you tweak the Real knobs, you'll see your changes in real-time.

Customizable Expression Pedal

The Expression Pedal can be used to control the volume or effects.

• WAH: Controls the WAH filter.
• EFX: Controls GAIN (DRIVE) parameter of OD/DIST. Or controls PITCH parameter of PITCH BENDER.
• AMP: Controls LEVEL parameter of AMP.
• MOD: Controls MIX level of Modulation effects.
• DLY: Controls MIX level of Delay effects.
• RVB: Controls MIX level of Reverb effects.

The Tech Features

Brand: Nux

Model: MG300

Type: Multi-Effects Pedals for Electric Guitar

IR: 25 Cabinets, 4 mics with 3 positions

Features:

• New Generation 32 bit DSP, 24bit 48kHz AD/DA
• Advanced Modeling Technology
• Drum and Phrase Loop Machine
• Tone Editing Computer Software
• Computer Recording Interface
• IR Cabinet Simulation
• 72 Presets
• Run's on Batteries or Adaptor(Included)
