As an artist, Tim Henson is always trying to update, invigorate and reinvent his band’s image. He has taken that same approach with the TOD10N, his signature nylon string electric guitar. The TOD’s most striking aesthetic feature may be the fingerboard inlay design, which Tim has dubbed as the “Tree of Death”.

MODIFIED FR HOLLOW BODY W/ FAN BRACING

Its thin, compact body and superior high fret access contribute to the superb playability of this guitar. It has less feedback as there’s no sound hole on the body top. Fan bracing, which is commonly used for classical guitars, allows this guitar to have a warm and natural nylon string sound.

''TREE OF DEATH'' FINGERBOARD INLAY
The name and the design of this fingerboard inlay are both nods to the iconic Ibanez “Tree of Life” inlay design, but with a twist.

SIDE SOUND PORT (TOD)
The sound port on the body side allows you to feel and hear the pure acoustic tone of this guitar more clearly and directly.

46MM WIDTH NUT / 400R FRETBOARD RADIUS
The combination of a narrow 46mm width nut and 400R fretboard radius offers easy fingering.

SPECS

body shape FRH body
bracing Fan Bracing for FRH
top Solid Sitka Spruce top
back & sides Sapele back & Sapele sides
neck C ShapeNyatoh neck
fretboard Walnut fretboard
bridge Walnut bridge
body binding Pearloid Binding
inlay Tree of Death inlay
tuning machine Gold Classical tuners
number of frets 22
strings D'Addario® XTC45
string gauge .0280/.0322/.0403/.028/.035/.044
string space 11.6mm
factory tuning 1E,2B,3G,4D,5A,6E
pickup Fishman® Sonicore
preamp Ibanez AEQ210TF preamp w/Onboard tuner
output jack 1/4" output
battery 9V battery
