Features

• 9x touch-sensitive motorized faders with 12-bit resolution
• Large, programmable 7 inch, 24 panel digital touch screen display showing DAW functions per 5 color modes – a potential total of 120 displayable and actionable functions
• Organize DAW functions in the 24 panel touchscreen easily via ‘drag and drop’ in the iMAPTM – changes made in real time
• Capability of connecting to 3 DAWs at one time via the DAW select buttons
• Extremely hardwearing, durable and versatile
• Onboard 2 inch TFT display showing channel name, control values, channel colors etc., (DAW dependent)
• Attractive, modern meter bridge, featuring precise, clear and eye-catching LED meters
• Additional lower 1.14 inch TFT display for each channel (some DAWs are equipped to display additional information on this screen)
• Extremely high quality, large optical encoder jog wheel with very precise, smooth control for fast search, scrub etc.
• 8 smooth action dual-function encoder knobs (Rotate and Enter)
• 2-segment LED display shows timecode or location of your project in either SMPTE or beat clock (bars:beats:ticks) formats
• Illuminated function buttons for ‘Read’, ‘Write’, ‘Touch’, ‘Latch’, ‘Trim’; and ‘Off’ – activated/deactivated as required per DAW
• Illuminated buttons for channel control including Mute, Solo and Record
• 6 illuminated transport buttons including Play, Stop, Record, Rewind, Fast Forward and Loop
• Dedicated ‘Master/Assign’ button for quick switching the Master fader from the master channel to a pre-designated track
• Illuminated “Zoom” button with 2 d directional keys (Left/Right & Up/Down), also used in combination with the jog wheel
• Illuminated ‘Focus’ button which allows the user to “focus” in and adjust plug-in, EQ parameters etc. via the smooth-action jog wheel
• 2 illuminated “Track” buttons for selecting individual channels
• 2 illuminated “Bank” buttons for shifting 8-channels at a time
• Supports Universal Mackie Control and HUI protocols for seamless integration with compatible music production software
• Supports Ability, Audition, Ableton Live, Bitwig, Cakewalk, Cubase/Nuendo, Digital Performer, FL Studio, Mixbus 32C, Pro Tools, Logic Pro, Luna, Reaper, Reason, Samplitude, Studio One and Tracktion Waveform
• iMapTM software downloadable from the product page
• USB C high-speed connectivity
• Firmware upgrade available via USB C connection and iMap TM software
• User A & User B 1/4 inch inputs for connecting footswitch pedals
• Class-compliant with MacOS 10.15 or above & Windows 10 or above
• Superior build quality and robust metal casing with Kensington lock port
