Key Features:
- 2 x 200 watts RMS class D amplification
- 10” custom woofer and 1” Celestion HF driver
- Integrated 7-channel mixer
- DSP with 16 FX Presets
- Bluetooth® audio streaming
- Standalone mono or stereo applications with LD MIX 10 G3
- Subwoofer and monitor outputs
- Rigid plywood enclosure
- Dual-Tilt pole mount for 0° or 5° orientation
The ideal choice for small-scale PA and personal monitoring applications, the active LD MIX 10 A G3 integrates a 7-channel mixer and Class D amplification with 2 x 400 watts peak power. The compact bass reflex loudspeaker features a 10″ custom woofer and 1″ Celestion HF driver complement, 65 Hz to 20 kHz frequency response and 90° x 60° dispersion delivering crystal clear sound with punch and detail.
Accomodating a wide variety of input sources including electric instruments, smartphones, tablets, MP3 and CD players, the built-in mixer provides 3 microphone channels with 2-band EQ, 48 V phantom power plus switchable hi-Z input (CH1) and stereo line channel. The output section includes a 3-band master EQ for overall tone shaping, 4-segment LED metering and XLR monitor and subwoofer outputs. In addition, the LD MIX 10 A G3 sports a DSP with 16 effect presets, limiter and overcurrent, overload, short circuit and thermal protection. A speakON output allows powering the passive LD MIX 10 G3 to easily create a stereo setup.
The rigid enclosure is constructed with tough plywood featuring a 50° monitor angle and Dual-Tilt pole receptacle for 0° or 5° mounting angles. On its own or in tandem with the passive unit, the LD MIX 10 A G3 provides amazing performance and versatility in a lightweight, easily portable package.
Technical Data
Type: | Active |
---|---|
Woofer dimensions: | 10 ” (254mm) |
Woofer brand: | Custom-made |
Tweeter dimensions: | 1 ” (25.4mm) |
Tweeter brand: | Celestion |
Dispersion (H x V): | 80 x 70° |
Frequency response: | 65 – 20.000 Hz |
Amplifier: | Class D |
Amplifier output (RMS): | 2 x 200 W |
Amplifier output (peak): | 2 x 400 W |
Max. SPL: | 124 dB |
Protection circuits: | Limiter , over-current , overload , short circuit , thermal overload |
Mixer Channels: | 7 |
Inputs: | 3x XLR/Jack (mic) with 1x Hi-Z input, 2x XLR/Jack (line), 1x 3.5mm Stereo Jack (AUX/Line) |
Outputs: | 1x XLR (monitor), 1x XLR (sub), 1x NL-2 Speakon (passive) |
Other Connections: | 1x footswitch |
DSP Presets: | 16 |
Dimensions: | 315 x 489 x 307 mm |
Weight: | 12.3 kg |
SKU | LDMIX102AG3 |
Brand | LDSYSTEMS |
